Advanced Aerospace Composite Materials
For more than 50 years, Permali has been a leading global aerospace supplier of Permaglass® advanced composite materials and machined components for civil and military fixed wing aircraft and helicopters.
Permali also manufactures an extensive range of blown film extruded Tuftane® thermoplastic polyurethane (TPU) elastomeric films. Tuftane® film grades are used for flexible, high performance barrier fabrics and textiles which must meet rigorous FAA aviation safety standards for aircraft and aerostats.
01.Cargo Bay & Cockpit Protection
For civil aircraft, FAR/CS 25 fire rated grades of Permaglass FRP composite sheet materials are used for passive cargo compartment fire protection bay liners, approved by Boeing, Fokker, Saab and BAE Systems. Cargo bay liners also need to provide a tough, hardwearing internal layer that can handle baggage and cargo handling containers. Permali also supplies fire resistant anti-ballistic armour plate protection for cockpit doors on commercial passenger aircraft.
Fire resistant, low smoke and fume Tuftane TPU film grades are used in aircraft interior floors and cabin furnishing materials, providing textiles and laminate materials with high durability, comfort and fire safety.
03.Inflatable Emergency Safety Equipment
Hydrolysis resistant Tuftane TPU films pigmented in bright safety colours are used in vital inflatable emergency safety equipment for passenger and flight crew: life jackets, life rafts and emergency door escape chutes. For aircraft emergency buoyancy aid equipment, Tuftane TPU film grades are formulated with additives to not only provide high elasticity, tear strength and puncture resistance, but to also be resistant to fungi and microbials. Equipment manufacturers are able to use RF welding techniques with Tuftane film to fabricate inflatables and products with high weld strength to meet required aviation safety standards.
04.Inflatable Fabrics for Aerostats
Unpowered semi-rigid, inflatable cable tethered aerostats, such as advertising blimps, barrage and weather balloons depend on an inert gas, such as hydrogen or helium, to provide the ‘lift’ and then remain suspended in the air. High elastic strength Tuftane TPU film grades are used in aerostats for the gas-filled fabric membrane, enabling it to remain inflated for prolonged periods of time. The Tuftane film also provides the elasticity to cope with extreme changes in temperatures and pressures between the ground and at operational altitudes.
Aircraft Composite Solutions
Permaglass® FRP sheet materials are supplied as semi-finished stock materials in aircraft approved fire rated cargo bay lining and ballistic grades, which can be cut to size if required.
Permali also has 3 & 5 axis CNC machining, bonding, coating, painting and assembly capabilities. This enables Permali to also supply ready to install bespoke fabricated composite finished components, including any metal fixtures, to an aerospace customer’s design and specifications.
The main applications where composite materials are specified for civil aircraft include:
01.Cargo Bay Liners
The key functions of a cargo bay liner is to prevent the spread of fire, smoke and toxic fumes (FST) from the cargo compartment and provide a durable internal lining. Cargo bay liners in passenger aircraft in particular need to be tough and very hardwearing, able to withstand repeated loose baggage impacts and wear from containers, boxes and pallets.
Permali supplies fire resistant (FR) aircraft cargo bay liners, manufactured using woven ‘E’ or ‘S’ glass fabrics with either an FR epoxy resin or FST rated phenolic resin grade. All Permaglass GRP composite sheet products used for cargo bay liner meet FAR/CS 25 flammability requirements and have approvals from Boeing, Fokker, Saab and BAE Systems approved.
02.Repair Patches for Cargo Bay Liners
For cost effective maintenance and repair of an operational aircraft, Permali supplies “peel and stick” patch product to repair damaged liners in situ. Cargo lining panels, particularly in passenger aircraft with loose baggage are prone to minor damage in small areas. The “peel and stick” repair patches are very quick and easy to apply by hand, requiring no special tools.
Permali’s cargo liner repair patches have been fully tested to meet the FAR25 App.F standard, with approvals from Boeing and Airbus.
03.Cockpit Door Armour
Permali has extensive expertise in anti-ballistic and blast protection composite armour, supplying the Land, Sea and Air Defence industry for over 80 years. For civil aircraft protection, fire resistant ballistic armour solutions are supplied for cockpit doors, which meet AC 25.795-2A and NIJ 0101.04 Level 3A standards. Permaglass ballistic grade stock sheet material or custom made CNC machined parts are supplied to manufacturers of civil aircraft cockpit door systems.
Tuftane TPU Film Solutions for Aircraft
Aerospace approved textiles, laminates and specialty fabric products in civil aircraft using Tuftane® TPU films include:
- Emergency exit inflatable evacuation chutes
- Passenger life vests/ infant buoyancy aids
- Inflatable life rafts
- Airline furnishings
- Airline flooring
